Model

I3HGP, I5HGP, I7HGP, 1037F

Processor

Intel I3-3217U, I5-3317U, I7-3517U , 1037U , 2117U

Chipset

Intel HM65/HM67/HM70/HM76

Memory

1x DDR3 Memory channel, support Max 8GB RAM;

Optional on-board 2GB RAM,up to 10GB RAM.

Ethernet

Realtek 8111E 1000Mbps LAN , optional 2xLAN.

Audio

Realtek ALC662 HD Audio,support Line-out,Mic-in,SPDIF, Speaker

CPU Graphics

Intel HD Graphics 4000,support 1080P(2K,FHD),H264,3D Play.

Display

VGA,HDMI,LVDS(Dual 8),optional AV port;

Support synchronously or asynchronously dual display.

Hard Disk

1xSATA3.0, 1xSATA2.0, 1xMSATA3.0

Power Supply

DC 12V, recommend 5A~10A

CPU_FAN

Thin silent cool fan,optional Fanless(Heat sink).

Form Factor

Mini-ITX ,170x170x18mm(L x W x H)

I/O Port

DC-in,HDMI,VGA,4xUSB,LAN,Line-out,Mic-in,optional AV.

Build-in Pin

LVDS,VGA,HDMI,4xUSB,2xCOM(Optional 6xCOM),optional GPIO,LPT,FAN,

SIM Card slot.

Expansion

2xMini-PCIE slots,support Wifi,4G/3G,Bluetooth,GPS,MSATA.

Temperature

-20℃ ~ 60℃(Working)             -20℃ ~ 70℃(Storage)

Working Humidity

5-95% relative humidity,non-condensing.

Operating System

Support Windows XP ,Windows 7 ,Windows 8 ,Windows 10 ,Linux.

Fitted Case

HD4000,HD4001,HD4003,IPC6000,OPS-1037U

Architecture

X86 architecture

Watch dog

Watch dog programming, support hardware reset function (256 levels, 0~255 seconds).

BIOS

AMI BIOS;Support read only,power on,timing switch,remote switch,

intelligently identify devices.

Purchasing Information:

MOQ

1 piece

Net Weight

0.4KG/piece

Package Size

20*20*7CM for 1 piece

Payment Ways

T/T,Western Union,Alipay,Wechat Pay,Paypal,Alibaba Trade Assurance,

RMB Cash,etc.

Delivery Time

1~3 working days

Shipping Ways

DHL,Fedex,UPS,TNT,etc.

Warranty

3 years for motherboard;1 year for CPU,RAM,SSD,HDD,WIFI,4G,etc.

OEM/ODM

Welcome

Certificates

CE , CCC , ISO , MSDS , UN38.3 , UN3091 , POA
